A carriage with metal rollers designed for self-supporting sliding gates. Used for various gate profiles and semi-closed C-sections. The gate carriages are galvanized and reinforced with yellow CR VI zinc, making them more durable and corrosion-resistant. The galvanic layer is approximately 8-12 um thick.
Advantages of the swinging carriage:
Carriage with a reinforced structure:
Thicker sheet metal has been used. The base of the carriage has been extended, making installation more comfortable.
Advantages of the additional adjustment plate:
The first lower assembling plate is screwed directly to the foundation base. The second base allows for adjustment of the correct height for the closed gate. This solution guarantees stable and strong attachment of the carriage to the foundation base.
The sliding carriages have metal rollers and two polyamide rollers.
We also recommend carriages made entirely of polyamide rollers!
Advantages of the polyamide roller with bearings:
Horizontally mounted guide rollers, at the front and back, of the carriage allow for perfect adjustment of the carriage to the gate guide. Additionally, horizontal rollers protect the vertical rollers from abrasion. The trolley with eight horizontal rollers is recommended for gates with a clear gate length of 6-10 m.
Carriage installation:
We install the carriages at the end of the gate in the so-called counterweight. It is assumed that the counterweight length is 1/3 of the clear gate length or in gates longer than 8 m approx. ½ of the clear gate length. The carriage's assembling plate has four elongated holes - so-called beans, where it is attached to the ground using an anchor or threaded rods. The maximum diameter of the bars is M16, and the recommended diameter is M14.
Gate load capacity: 800 kg.
Gate length in clear: 6–10 mb.
Assembling plate: TYP "B" - optional.
We are a manufacturer with over 40 years of experience in the production of plastic and metal products. We have a large warehouse to maintain a deep inventory. Our committed customer service team will quickly handle even the biggest and most demanding orders, including custom-made orders. To ensure top-quality service to our customers, we will gladly examine your requests and prepare an attractive quote. Requests should be sent to: order@tulplast.pl
