A carriage with metal rollers designed for self-supporting sliding gates. Used for various gate profiles and semi-closed C-sections. The gate carriages are galvanized and reinforced with yellow CR VI zinc, making them more durable and corrosion-resistant. The galvanic layer is approximately 8-12 um thick.
Steady carriage:
Steady carriages are used for non-standard gates with too short a counterweight. The advantage of installing such carriages is achieving minimal tilt when opening the gate.
Advantages of the additional adjustment plate
The first lower assembling plate is screwed directly to the foundation base. The second base allows for adjustment of the correct height for the closed gate. This solution guarantees stable and strong attachment of the carriage to the foundation base.
The sliding carriages have polyamide rollers or metal rollers.
Advantages of the polyamide roller with bearings:
Carriage installation
We install the carriages at the end of the gate in the so-called counterweight. It is assumed that the counterweight length is 1/3 of the clear gate length or in gates longer than 8 m approx. ½ of the clear gate length. The carriage's assembling plate has four elongated holes - so-called beans, where it is attached to the ground using an anchor or threaded rods. The maximum diameter of the bars is M16, and the recommended diameter is M14.
Gate load capacity: 400 kg.
Gate length in clear: 3–5 m.
Assembling plate: TYPE „A” - standard, TYPE "B" - option
* The carriage is sold without a secure cover. It is recommended to install a cover made of ABS.
Possibility to purchase a secure cover in a set with the carriage.
Carriage compatible with carriage secure cover type: OZPW/B
